M Piezoelectric Poling System

Name: M Piezoelectric Poling System
Brand: MatMeas

MatMeas MPD Series Four‑Channel High Voltage Polarization System — 1

Overview

The MPD Series Four‑Channel High Voltage Polarization System from MatMeas is designed for precise oil‑bath polarization of piezoelectric ceramic samples. The system supports simultaneous polarization of multiple samples and provides independent high‑voltage output channels to ensure stable and interference‑free operation. With advanced safety protection, intelligent monitoring and multiple polarization modes, the MPD system helps researchers achieve optimal polarization performance. It is widely used in aerospace technology, laser gyroscope research, adaptive optics, precision machinery, automatic control systems, semiconductor integration and biomedical engineering laboratories.

Specifications

Parameter	Value
Polarization Method	Oil Bath Polarization
Polarization Voltage	0–30 kV / 0–40 kV / 0–50 kV optional
Polarization Current	Max 5 mA per channel
Voltage Output Accuracy	±1 %
Minimum Detection Current	≥100 nA
Temperature Range	RT – 300 °C
Temperature Control Accuracy	±1 °C
Heating Control	PID precise temperature control
Heating Rate	1°C/min, 3°C/min, 5°C/min
Sample Size	d ≤ 50 mm, φ ≤ 50 mm
Insulation Material	Alumina ceramic and PTFE
Power Supply	220 V / 50–60 Hz
Power Consumption	1500 W
Weight	25 kg

Applications

Piezoelectric ceramic polarization research
Materials science laboratories
Aerospace component development
Semiconductor device research
Biomedical engineering and precision electronics

More Details

MPD Polarization System Features
The MPD system supports ramp voltage polarization, step voltage polarization and pulse polarization modes to meet different experimental requirements. Each channel operates independently with high‑voltage output protection and breakdown monitoring.
MPD Safety Design
The instrument integrates electrical isolation shielding and safety interlock protection to prevent accidental operation. If the interlock device is not engaged, the system will automatically alarm and block voltage output to ensure user safety.
MPD Intelligent Monitoring
The system provides real‑time visualization of polarization parameters, polarization current and polarization status, allowing researchers to monitor the entire process and improve experiment efficiency.
